Animated Scrolling Text in 16×2 LCD using 8051 Microcontroller

July 19, 2014 6 Comments

8051 Tutorials

animation-scrolling-text-lcd-16x2-8051-microcontroller
Scrolling text animation in 16×2 LCD

LCD’s are widely used where user interaction with the system is necessary and you might have come across static message display using LCD. The message displayed on the LCD can also be animated like blinking, scrolling etc. This article explains how to display a running or animated scrolling text in a 16 x 2 LCD display with a 8051 Microcontroller.

16 x 2 LCD:

pin-diagram-configuration-16x2-lcd-display
16×2 LCD Display

In a 16 x 2 LCD a message is displayed by means of configuring it through commands initially and data to be displayed is sent. A two registers namely Command and Data register are used to serve this purpose in a LCD. Learn about programming LCD if you are not aware of it.

It only take few extra steps to make text scrolling in a LCD screen. There are two specific commands which we use for the purpose of text scrolling. They are

0x18 – Shift Entire Display Left

0x1C- Shift Entire Display Right

Using these commands we have to shift our message either left or right continuously by means of placing it in an infinite loop. Doing this we can achieve the scrolling effect of Message in LCD from right to left or vice versa.

CODE:

#include<reg51.h>
#include<string.h>
void delay(void);
sbit rs=P3^0;
sbit rw=P3^1;
sbit en=P3^2;
code unsigned char a[3]={0x38,0x0f,0x06};
code unsigned char b[12]="GADGETRONICX";
unsigned int i,j,k,l;
void cmdwrite()
  {
    rs=0;
    rw=0;
    en=1;
    delay();
    en=0;
  }
void datawrite()
  {
   rs=1;
   rw=0;
   en=1;
  delay();
  en=0;
  }
void delay()
  {
   for(k=1;k<4000;k++);
    {
      for(l=1;l<=5000;l++);
    }
  }
void main()
{
for(i=0;i<=2;i++)
{
P1=a[i];
cmdwrite();
delay();
}
P1=0x80;
cmdwrite();
delay();
for(j=0;j<=11;j++)
{
P1=b[j];
datawrite();
}
while(1)
{
P1=0x18;
cmdwrite();
delay();
}
}
